High air flow & tank size to power multiple high-demand air tools
2-stage pump made to deliver more than 15,000 hours of operation
Ideal for auto repair facilities and tire repair outlets
- Peace of Mind with Every Purchase
- Free and fast shipping worldwide
- Your Security is Our Promise
- The Quality Choice for Smart Shoppers
The Campbell Hausfeld 80 Gal., 5 HP, vertical, 2-stage air compressor (CE7051) is ideal for auto repair facilities and tire repair outlets. This air compressor has a high air flow of 17.2 CFM at 90 PSI to power air tools. Operating on three-phase electric power, its rugged motor drives a long-life, cast-iron, 2-stage pump that’s designed to deliver more than 15,000 hours of operation. The pump head and valve plate feature an advanced design with Viton(r) high-temperature O-rings for superior high-pressure sealing when compared to paper gaskets. For smooth, low-vibration operation, the crankshaft is fabricated of ductile iron and optimally balanced.
- ASME certified tank for 175 PSI maximum pressure, finish your projects faster and easier with Campbell Hausfeld – the air power expert
- 80 Gal. tank, 17.2 CFM at 90 PSI, 175 max PSI, 208-230/460-Volt, 14.2-12.8/6.4 Amp, 3 phase, 60 Hz
- Commercial duty cast iron, oil-lubricated, 2-stage pump to deliver more than 15,000 hours of operation, mounted and wired motor starter for quick electrical hook up
- Pump head and valve plate feature an advanced design with Viton(r) high-temperature O-rings for superior high-pressure sealing when compared to paper gaskets, industrial-rated NEMA motor for reliable service
| Air Delivery SCFM @ 40PSI | 16.7 |
|---|---|
| Tank Style | Vertical |
| Power Type | Corded Electric |
| Product Weight (lb.) | 540 |
| Reconditioned | No |
| Returnable | 90-Day |
| Stage Count | Two Stage |
| Tank Material | Steel |
| Tools Product Type | Air Compressor |
| Portable | No |
| Voltage (v) | 208-230/460v |
| Voltage (volts) | 208-230/460 V |
| Certifications and Listings | CSA Listed |
| Manufacturer Warranty | 3 year limited |
| Product Depth (in.) | 35 |
| Product Height (in.) | 78 |
| Power Source | Electric |
| Phase Type | 3 Phase |
| Air Delivery SCFM @ 90PSI | 17.2 |
| Compressor Type | Garage & Industrial |
| Amperage (amps) | 14 A |
| Application Use | Air Brushing,Blow Cleaning,Bolting/Wrenching,Brad Nailing/Stapling,Cutting,Drilling,Finish Nailing,Framing Nailing,Grinding,HVLP Painting,Inflation,Sanding,Spraying,Surface Prep |
| Battery Amp Hours | No Battery |
| Battery/Charger | Tool Only |
| Charger Included | Charger Not Included |
| Compressor Tank Capacity (Gallons) | 80 gal |
| Compressor Volume Rating | Standard |
| Number of Total Batteries Included | 0 |
| Compressor/Air Tool Features | Tank Pressure Gauge |
| Condition | New |
| Decibel Rating (Outdoor) | 85 dBA |
| Horsepower (hp) | 5 hp |
| Included | No additional components or accessories are included |
| Lubrication Type | Oil-Lubricated |
| Maximum Pressure (psi) | 200 psi |
| Product Width (in.) | 42 |
